Kegyma AC Electrical Socket with TWIN USB-C Receptacle
Wall outlet with USB ports ensures all your devices stay charged while leaving room for other appliances. Charge two USB devices simultaneously without adapters.
Key Features:
- 5.0A, 5VDC combined charging capacity; each USB port can reach up to 5.0A on a standalone charge
- Provides the fastest charge to iPhone, iPad, iPad Air, and other smartphones, tablets, and USB devices
- Smart and safe charging with intelliChip built into the USB ports
- Recognizes power needs of connected devices and delivers maximum power up to 5.0A per port
- Child safe, tamper-resistant duplex receptacle increases safety
- Back and side wired; 125VAC, 15A duplex receptacle, ETL-listed 5001170
Technical Specifications
| Amperage |
15 Amp |
| Voltage |
110V-240V |
| Pole |
2 |
| Wire |
3 |
| Grounding |
General Grounded |
| Dielectric Voltage |
Withstands 2000V per UL498 |
| USB Output |
Single Max 5.0A |
| Terminal Accommodation |
14-10 AWG |
| Flammability |
Rated V-2 per UL94 |
| Operating Temperature |
-10°C to 40°C |
| Face Material |
100% pure PC |
| NEMA |
5-15R |
| Applicable Standards |
UL 943, UL 498 |
Product Advantages
Wide Voltage Design
Supports 110V to 240V, making it suitable for use in both South America and North America as well as other American standard areas.
Fast Charging USB Port
Single port supports maximum 5.0A current. USB 5.0A employs identification chip to enable optimum power transfer while maximizing charging efficiency.
Tamper Resistant Shutter
Complies with NEC® requirement - all 15A and 20A receptacles installed in dwelling units should be tamper-resistant. Receptacles with shutter mechanism block access to the contacts unless the plug is fully inserted, providing enhanced safety for children.
Intelligent Identification Chip
Equipped with smart chip, the USB ports precisely 'read' the power needs of connected devices to deliver optimal power. IntelliChip charges at the optimal power allowed by the device, protecting your devices from overcharging and overheating.
Applications
Residential and Commercial Applications:
Kitchens, Bedrooms, Home Offices, Airport Lounges, Salons and Spas, Hotels, Meeting Rooms, Office Cubicles, College Dormitories, Cafes, Coffee Houses, Restaurants or other public areas.
From the bedroom to the airport, from the living room to the library, the KU-15T 4.2A USB Charger Outlet is perfect for any application! Your walls will look tidy and neat, while giving your devices a better power center. All you need is your USB cable.
